Feta net weight: 23g
Package weight: 71.5g
Package size: 64*64*35mm
Specification size of flight control
Fly control size: 36x36mm
Net weight of flight control: 8.5g
Mounting hole distance: 30.5*30.5mm φ4mm
Processor: STM32F405RET6
Gyro: ICM42688
B E C : 5V/3A ; 10V/2.5A
Memory: 16MB
Input Voltage: 2S-6S
Firmware: HAKRCF405V2
Uart serial port: 5
Comes with four programmable phantom LEDs
Comes with 6P sky terminal holder
RX2 connected to SBUS
50A ESC parameters
ESC size: 44mm*44mm
ESC net weight: 13.5g
Fixed hole pitch: 20/30.5mm-20/30.5mm Φ4mm
Continuous current: 50A
Maximum current: 60A (can last 10S)
Input voltage: 2S-6S
Current ratio: 160
Adjustment software: BLHeliSuite16.7.14.9.0.3
Drive signal support: PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600
65A ESC parameters
ESC size: 42.5mm*45mm
Net weight of ESC: 15g
Fixed hole distance: 30.5mm-30.5mm Φ4mm
Continuous current: 65A
Maximum current: 75A (can last 10S)
Input voltage: 2-6S
Current ratio: 160
Parameter adjustment software: BLHeliSuite32Activator_32.9.0.3
Drive signal support: PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600
Accessory List
M3 orange shock ball x8, 8p cable x2, LED4P cable x1, CRSF Receiver4P cable x1,DJI6P connecting cable x1, Capacitor (35v470uf) x1, XT60 power header x1, red and black power cable x1, (M3x25mm screws) x4, black nut x4
