X-38cc-S
Displacement: 38cc (2.33 cu in)
Performance: 4.2HP
Speed Range: 1800-7300 RPM (Test Propeller-20*9)
Bore: 39mm (1.54 in)
Stroke: 32.5mm (1.28 in)
Static Thrust: 10.5 kg @ 100 m ALT (23.1 lb @ 328 ft ALT)
Static Thrust: 8.5 kg @ 1800 m ALT (18.7 lb @ 5900 ft ALT)
Compression ratio: 9:1
Lubrication ratio: 30:1 (Fuel: 2-Stroke Motor Oil)
Ignition Voltage: 6-14 V
Spark Plug Type: CM6 Iridium Spark Plug
Recommended Propeller: 19x8; 19x10; 20x8; 20x10
Weight of Main Engine: 1010g
Weight of Muffler Set: 73g
Weight of Aluminum Standoffs Set: 100g
Weight of Spark Plug: 13.5g
Weight of CDI (Ignition): 104g
Total Weight: 1300.5g (2.87 lb)
X-38cc-R
Displacement: 38cc (2.33 cu in)
Performance: 4.2HP
Speed Range: 1800-7300 RPM (Test Propeller-20*9)
Bore: 39mm (1.54 in)
Stroke: 32.5mm (1.28 in)
Static Thrust: 10.5 kg @ 100 m ALT (23.1 lb @ 328 ft ALT)
Static Thrust: 8.5 kg @ 1800 m ALT (18.7 lb @ 5900 ft ALT)
Compression ratio: 9:1
Lubrication ratio: 30:1 (Fuel: 2-Stroke Motor Oil)
Ignition Voltage: 6-14 V
Spark Plug Type: CM6 Iridium Spark Plug
Recommended Propeller: 19x8; 19x10; 20x8; 20x10
Weight of Main Engine: 1040g
Weight of Muffler Set: 73g
Weight of Aluminum Standoffs Set: 100g
Weight of Spark Plug: 13.5g
Weight of CDI (Ignition): 104g
Total Weight: 1330.5g (2.93 lb)
XG-38cc-S
Displacement: 38cc (2.33 cu in)
Performance: 4.2HP
Speed Range: 1800-7300 RPM (Test Propeller-20*9)
Bore: 39mm (1.54 in)
Stroke: 32.5mm (1.28 in)
Static Thrust: 10.5 kg @ 100 m ALT (23.1 lb @ 328 ft ALT)
Static Thrust: 8.5 kg @ 1800 m ALT (18.7 lb @ 5900 ft ALT)
Compression ratio: 9:1
Lubrication ratio: 30:1 (Fuel: 2-Stroke Motor Oil)
Ignition Voltage: 6-8.4 V
Glow Plug Type: E8 (or OS G5) Glow Plug & AET Power System
Recommended Propeller: 19x8; 19x10; 20x8; 20x10
Weight of Main Engine: 1010g
Weight of Muffler Set: 73g
Weight of Aluminum Standoffs Set: 100g
Weight of Glow Plug: 3.6g
Weight of AET (Ignition): 30g
Total Weight: 1217g (2.68 lb)
XG-38cc-R
Displacement: 38cc (2.33 cu in)
Performance: 4.2HP
Speed Range: 1800-7300 RPM (Test Propeller-20*9)
Bore: 39mm (1.54 in)
Stroke: 32.5mm (1.28 in)
Static Thrust: 10.5 kg @ 100 m ALT (23.1 lb @ 328 ft ALT)
Static Thrust: 8.5 kg @ 1800 m ALT (18.7 lb @ 5900 ft ALT)
Compression ratio: 9:1
Lubrication ratio: 30:1 (Fuel: 2-Stroke Motor Oil)
Ignition Voltage: 6-8.4 V
Glow Plug Type: E8 (or OS G5) Glow Plug & AET Power System
Recommended Propeller: 19x8; 19x10; 20x8; 20x10
Weight of Main Engine: 1040g
Weight of Muffler Set: 73g
Weight of Aluminum Standoffs Set: 100g
Weight of Glow Plug: 3.6g
Weight of AET (Ignition): 30g
Total Weight: 1247g (2.75 lb)
X-38cc-S PRO
Displacement: 38cc (2.33 cu in)
Performance: 4.2HP
Speed Range: 1800-7300 RPM (Test Propeller-20*9)
Bore: 39mm (1.54 in)
Stroke: 32.5mm (1.28 in)
Static Thrust: 10.5 kg @ 100 m ALT (23.1 lb @ 328 ft ALT)
Static Thrust: 8.5 kg @ 1800 m ALT (18.7 lb @ 5900 ft ALT)
Compression ratio: 9:1
Lubrication ratio: 30:1 (Fuel: 2-Stroke Motor Oil)
Ignition Voltage: 6-14 V
Spark Plug Type: CM6 Iridium Spark Plug
Recommended Propeller: 19x8; 19x10; 20x8; 20x10
Weight of Main Engine: 1186g
Weight of Muffler Set: 73g
Weight of Aluminum Standoffs Set: 100g
Weight of Spark Plug: 13.5g
Weight of CDI (Ignition): 104g
Weight of Starter: 109g
Weight of ESC: 36g
Total Weight: 1512.5g (3.33 lb)
X-38cc-R PRO
Displacement: 38cc (2.33 cu in)
Performance: 4.2HP
Speed Range: 1800-7300 RPM (Test Propeller-20*9)
Bore: 39mm (1.54 in)
Stroke: 32.5mm (1.28 in)
Static Thrust: 10.5 kg @ 100 m ALT (23.1 lb @ 328 ft ALT)
Static Thrust: 8.5 kg @ 1800 m ALT (18.7 lb @ 5900 ft ALT)
Compression ratio: 9:1
Lubrication ratio: 30:1 (Fuel: 2-Stroke Motor Oil)
Ignition Voltage: 6-14 V
Spark Plug Type: CM6 Iridium Spark Plug
Recommended Propeller: 19x8; 19x10; 20x8; 20x10
Weight of Main Engine: 1216g
Weight of Muffler Set: 73g
Weight of Aluminum Standoffs Set: 100g
Weight of Spark Plug: 13.5g
Weight of CDI (Ignition): 104g
Weight of Starter: 109g
Weight of ESC: 36g
Total Weight: 1542.5g (3.4 lb)
XG-38cc-S PRO
Displacement: 38cc (2.33 cu in)
Performance: 4.2HP
Speed Range: 1800-7300 RPM (Test Propeller-20*9)
Bore: 39mm (1.54 in)
Stroke: 32.5mm (1.28 in)
Static Thrust: 10.5 kg @ 100 m ALT (23.1 lb @ 328 ft ALT)
Static Thrust: 8.5 kg @ 1800 m ALT (18.7 lb @ 5900 ft ALT)
Compression ratio: 9:1
Lubrication ratio: 30:1 (Fuel: 2-Stroke Motor Oil)
Ignition Voltage: 6-8.4 V
Glow Plug Type: E8 (or OS G5) Glow Plug & AET Power System
Recommended Propeller: 19x8; 19x10; 20x8; 20x10
Weight of Main Engine: 1186g
Weight of Muffler Set: 73g
Weight of Aluminum Standoffs Set: 100g
Weight of Glow Plug: 3.6g
Weight of AET (Ignition): 30g
Weight of Starter: 109g
Weight of ESC: 36g
Total Weight: 1429g (3.15 lb)
XG-38cc-R PRO
Displacement: 38cc (2.33 cu in)
Performance: 4.2HP
Speed Range: 1800-7300 RPM (Test Propeller-20*9)
Bore: 39mm (1.54 in)
Stroke: 32.5mm (1.28 in)
Static Thrust: 10.5 kg @ 100 m ALT (23.1 lb @ 328 ft ALT)
Static Thrust: 8.5 kg @ 1800 m ALT (18.7 lb @ 5900 ft ALT)
Compression ratio: 9:1
Lubrication ratio: 30:1 (Fuel: 2-Stroke Motor Oil)
Ignition Voltage: 6-8.4 V
Glow Plug Type: E8 (or OS G5) Glow Plug & AET Power System
Recommended Propeller: 19x8; 19x10; 20x8; 20x10
Weight of Main Engine: 1216g
Weight of Muffler Set: 73g
Weight of Aluminum Standoffs Set: 100g
Weight of Glow Plug: 3.6g
Weight of AET (Ignition): 30g
Weight of Starter: 109g
Weight of ESC: 36g
Total Weight: 1459g (3.22 lb)
